Custom Aluminum Extrusions

FONNOV ALUMINIUM has been a professional custom aluminum extrusion manufacturer since 2004.

FONNOV ALUMINIUM is trying to be one of the best custom aluminum extrusion companies and suppliers.

Our Goal is To Make Your Great Ideas Happen To Real.

aluminum extrusion profiles 4-fonnovaluminium

The Benefit You Can Get From Custom Aluminum Extrusions

round heatsink solid type-fonnovaluminium
aluminum heat sink-fonnovaluminium
MAKE YOUR DRAWING TO REAL

You may purchase standard aluminum extrusions (usually aluminum bars, aluminum rods, or aluminium tubes, T-slot aluminium profiles, aluminum beams) for your needs by further machining. But sometimes, these standard aluminium profiles on stock may not work. A custom aluminum extrusion is designed based on your final use, which will bring less material waste and less cost on additional machining and secondary finishing and save more money for you. Most Custom aluminum extrusion can be used directly for the final application.

  • Custom aluminum extrusions are good at creating complex cross-sectional shapes.
  • Custom aluminum extrusions can be produced with a wide range of aluminum alloy grades for different mechanical properties.
  • Custom aluminum extrusions can be shaped with close tolerance for your use.
  • Custom aluminum extrusions can be coated with all kinds of finishes.
  • Custom aluminum extrusions can also be machined and fabricated with holes and markings for your final use.

What can FONNOV bring you on Custom Aluminum Extrusions?

Fonnov aluminium creates aluminum cross-sections much closer to your design, and we will assist in amending the design for your final use. What we can provide you is to make your assembly better.

The best custom aluminum extrusion manufacturer always starts with a well understanding of the end user’s needs. With years of experience in custom aluminum extrusion manufacturing, FONNOV can deliver customers’ precision custom aluminum extrusions.

Fonnov’s experts will work closely with you to understand your needs and design. We can assist you with your design and evaluate whether the design is right for you, whether the material is suitable for you, and whether the custom aluminum extrusion is proper. We can only manage the die program for correct production when every detail is approved. We need to make sure your design and tolerance are workable for extrusion.

Fonnov is your single source supplier of custom aluminum extrusions.

Surface Finishing Options For Custom Aluminum Extrusions

Loading...

POWDER COATING

  • FONNOV produces powder-coated custom aluminum extrusions.
  • We provide you with a wide range of RAL color and PANTONE color options.
  • The coating appearance textures can be smooth, sandy, and metallic.
  • The gloss can be matt, satin, and high gloss.
  • Suitable for residential and commercial architectural aluminum extrusion profiles.
  • Both indoor and outdoor use.
  • Widely used in window/door frames, railings, lighting, machinery, gym equipment, household appliance, etc.
Loading...

WOOD FINISH

  • FONNOV produces wood grain custom aluminum extrusions.
  • We provide you with a wide range of wood color options: oak, teak, walnut, cherry, etc.
  • The coating appearance textures can be smooth and sandy.
  • Suitable for residential and commercial architectural aluminum extrusion profiles.
  • Both indoor (10 years warranty) and outdoor use (15 years warranty).
  • Widely used in window/door frames, railings, ceiling, wall screening, pergola, louvers, fencing, decking, etc.
Loading...

ANODIZING

  • FONNOV produces anodized custom aluminum extrusions.
  • We provide you with anodizing colors: clear anodizing, black anodizing, bronze, champagne.
  • The textures can be smooth, polishing, brushed, or sandblasted.
  • The gloss can be matt and glossy.
  • Suitable for industrial aluminum extrusion profiles.
  • Both indoor (AA10) and outdoor (AA15 & AA20) use.
Loading...

PVDF & WET PAINTING

  • FONNOV produces wet-painted custom aluminum extrusions.
  • We provide you with a wide range of color options.
  • The coating appearance textures can be smooth and metallic.
  • The gloss can be matt and glossy.
  • Suitable for commercial landmark architectural buildings.
  • Super durable outdoor use (30 years warranty).

Select the Right Alloy for Custom Aluminum Extrusions

An aluminum alloy for custom aluminum extrusion is a necessary factor for customers to consider. Different mechanical properties will be brought by custom aluminum extrusion with alloy 1xxx, 2xxx, 3xxx, 5xxx, 6xxx, and 7xxx series. Although aluminum alloy 6060 6063 6061 6082 are considered the best choices for aluminum extrusion manufacturing, they may not be suitable for your needs.

Customers need to pay more attention to these features when choosing the suitable alloy for custom aluminum extrusions.

  • Application
  • Hardness
  • Strength
  • Corrosion Resistance
  • Formability
  • Machining Capability
  • Weldability
aluminium profile 6063 aluminum fonnov

MACHINING & FABRICATION for Custom Aluminum Extrusions

cnc machining-fonnovaluminium

CNC MACHINING

aluminum welding-fonnovaluminium

WELDING

aluminum profile assembly-fonnovaluminium

ASSEMBLY

aluminum bending-fonnovaluminium

BENDING

cnc sawing-fonnovaluminium

CNC SAWING CUTTING

hole punching-fonnovaluminium

HOLE PUNCHING

LASER ETCHING

Custom Aluminum Extrusions FAQ

Can I use 6061T6 instead of 7075T6?2023-02-28T03:35:14+00:00

Different aluminum alloy and temper is with different mechanical properties, as well as different requirement in application. Click How to Choose Aluminium Profiles: 7075T6 VS 6061T6 to see the differences of 6061T6 and 7075T6, which can help you to confirm the material that you need for production.



What is the max. width you can extrude?2023-05-04T04:12:59+00:00

The max. width that we can do depends on the exact profile shape. Please send us your CAD drawings for a brief check firstly.

The wider the cross-section, the larger the extrusion press is needed. Our largest capability is with width 500mm for some shapes. Many construction companies will be concerned about the maximum width that an aluminum extruder can do. For example, the width of the aluminum formwork usually needs to be at least 300mm.

In cooperation with top institutions in China, we offer and produce aluminum extrusions with a maximum section width of 1100mm. We are working with many famous transportation companies on large size aluminum extrusions.



4000ton extrusion press-fonnovaluminium

Can you provide machining service for extrusion order?2023-05-04T04:13:17+00:00

We have an aluminum fabrication shop to provide CNC machining and fabrication service.
The material is not only aluminum extrusion products but also aluminum sheet panels. Please send us your CAD and 3D drawings for a quote.

Click Aluminum Machining / Fabrication to know more.

CNC Machining On Heatsinks

Can I get your newest timber look aluminum colorchart?2022-04-30T01:49:19+00:00

FONNOV ALUMINIUM is very famous for woodgrain aluminum among our customers. We have made more than 1000 wood colors. Anual popular timber-look colors will be published in each early year.

Click Timber Look Aluminum Color chart to see the updated wood grain colors. They are popular in our existing market in the US, UK, Australia, Singapore, etc. Or email us your project for suggestions.

wood aluminum ceiling color -fonnov aluminium

What is the difference of 6060 and 6063?2022-04-30T01:49:30+00:00

Some countries prefer to use aluminum extrusion with alloy 6060 for production, and some countries perfer to use 6063 instead. The mechanical properties are nearlly the same. Click 6060 VS 6063 to see details of the two popular aluminium alloy for production.

6063 aluminium ingot for extrusion-fonnov



Profile Length for Delivery2023-02-28T03:34:32+00:00

Max. L=5800mm for 20 container ( choose 40 container if L>5900mm)

Max. L=3000mm for LCL goods by sea (contact shipping agent for goods with L>3000mm, some shipping company accept with a higher cost.)

Max. L=2000mm for EXPRESS



Delivery Ports2023-02-28T03:34:42+00:00

The ports near FONNOV are LIANYUNGANG, QINGDAO, SHANGHAI. Our suggestion:

QINGDAO PORT for FCL goods

SHANGHAI PORT for LCL goods

You can consult your shipping forwarder for the most suitable delivery port.





Packing & Loading Details2023-02-28T03:34:57+00:00

aluminum extrusion packing loading-fonnovaluminium

▹Bundle Packing

Inside Packing Material: plastic protective film for each piece / plastic bag for each piece / none (optional)

Outside Packing Material: bundles by waterproof craft paper / EPE film / shrink film (optional)

▹Carton Packing

Inside Packing Material: plastic bag for each piece / none (optional)

Outside Packing Material: by carton

▹Wood Pallet Packing

Inside Packing: carton packing

Outside Packing Material: wood pallet

▹Plywood Case Packing

Inside Packing: bundle packing

Outside Packing Material: plywood case



What is the difference of 6063T5 and 6063T6?2022-04-30T01:50:09+00:00

Different temper is with different mechanical properties and prices, as well as different requirement in application. Click 6063T5 VS 6063T6 to see the differences of T5 and T6 of 6063 aluminum alloy, which can help you to select the material that you need for production.





What is your aluminum extrusion process?2022-04-30T01:50:37+00:00

Click Aluminum Extrusion Process from FONNOV ALUMINIUM Old Factory to see the aluminum extrusion process in our plant.

What is your MOQ?2022-07-10T01:38:13+00:00

Generally 500KG per design.

1TON per design for 7075T6 extruded profiles.

How long for the sample?2022-07-10T01:49:01+00:00

Sample / Die (Mould): within 15-20 days after payment & drawing are confirmed by clients.

What is your delivery time2022-04-30T01:51:18+00:00

Batch Production: 20-25 days after sample confirmed & down payment received.

What should I provide for a quote from you?2023-02-28T03:35:38+00:00

▹Drawing is necessary. CAD drawing for aluminum extrusion request. CAD and 3D drawing for machining and fabrication request.

▹Required quantity / aluminium alloy and temper / surface finishing / dimension tolerance / quality standard.

The information above is all needed for the price. Please let us know more about your aluminum project.



Can I get a sample?2022-04-30T01:51:40+00:00

▹If we have existing die for your required profile, we can produce sample, but EXPRESS charge will be in your account.

▹If we don’t have existing die for your design, you should pay die charge and Express charge for samples.

▹Sample is free for quantity <1M. If quantity is more than 1M, we will charge for sample.



What is your payment term?2022-04-30T01:51:54+00:00

▹30% T/T in advance, 70% T/T should be paid before delivery.

▹L/C at sight

Note: Settlement term for balance payment: final quantity shall be based on actural phsical weight including packing (standard pound worse tolerance ± 3%)

READY TO START A CUSTOM ALUMINUM EXTRUSION?

Let’s get started from your ideas.

We will answer your EMAIL within 1 day!
