LARGE DIAMETER ALUMINUM TUBES

large aluminum tubes-fonnovaluminium

FONNOV ALUMINIUM is a large diameter aluminum tubes manufacturer and supplier (aluminum OD>100MM).

  • We produce and supply large diameter aluminum tubes upto OD600mm.
  • We produce 6061T6 seamless large diameter aluminum tubes.
  • We can produce thin wall large diameter aluminum pipes and heavy wall large diameter aluminum tubes.
  • We provide finishing and machining services for your large diameter aluminum tubes order.

Select The Size For Large Aluminum Tubes



Fonnov has hundreds of existing dies for large diameter aluminum tubes to help you save costs.

The list is updating. Contact us if you can not find the dimension you require.

Click HERE for OD<100MM aluminum round tubes.

aluminum-round-tube1-fonnovaluminium

SIZE CHART(updating) – LARGE ALUMINUM TUBES OD>100MM

OD (mm) Thickness (mm)
100 2.5
100.8 8.4
106.7 10.4
114 5.0 / 6.0
115 1.8
120 1.4 / 1.5 / 1.8 / 2.8
125 1.5
127 2.0
150 2.4 / 2.8
157 2.2
170.1 1.8
185 1.45
200 3.0
205 5
210 5/34
220 40
273 7/10/12.7/15.1
280 50
300 10
320 20
324 12/14.3/21.5/35.5
356 10.5/28
470 8
508 8
512 8
540 8/10
570 8
600 8
626 8
UPDATING…

More Options For Large Diameter Aluminum Tubes

Product name

large diameter aluminum tube, large diameter aluminum pipe, large diameter aluminum tubing, large aluminum tubes, large aluminum tubing, aluminum tube large diameter, large aluminum pipe, large aluminium tube.

Description Large diameter aluminum tube refers to the outer diameter of the aluminum tube is more than 100mm. Sometimes it is also defined as an aluminum tube with an outer diameter of more than 200mm.
Material aluminum alloy 6061, 6063, 2024, 5083, 7075, etc.
Temper T4, T5, T6, etc.
Finish & Color anodizing, powder coating, sandblasting anodizing, brushed anodizing, etc.
Length CNC cut-to-length as per request.
Packing wooden frame, plywood case, shrink film.
Application Large diameter aluminum tube and pipe has good strength and corrosion resistance. Large diameter aluminum tube and pipe is widely used in manufacturing welded pipe, oil and gas pipeline and water pipe. It can also be used in the manufacture of high-pressure vessels.

What You Can Do With Large Diameter Aluminum Tubes

Large diameter aluminum tube (or pipe) most suitable for general structural piping and mechanical structure of the pipeline, including the transport of water, oil, gas and other fluids pipeline.  Because of the use of a variety of different large diameter aluminum pipe, so their use is also different.  Because of the different uses, so the large diameter aluminum tube sizes and dimensions are different.

What FONNOV provide you on large diameter aluminum tubes

aluminium alloy 6063 extrusion fonnov

Aluminum Alloys For Large Diameter Aluminum Tubes

  • Alloy 6061 Large Diameter Aluminum Tubes (similar to alloy 6082)

The 6061T6 seamless large diameter aluminum tube is of high strength and hardness.

  • Alloy 6063 Large Diameter Aluminum Tubes (similar to alloy 6060)

The 6063T5 is the most preferred material for large diameter aluminum tube manufacturing. Comapred with 6061 aluminium, the 6063 large diameter aluminum tube has a lower strength and hardness.

anodizedcolors-fonnovaluminium(1)

Finishings For Large Diameter Aluminum Tubes

  • Anodizing

The large diameter aluminum tubes can be anodized to silver color, black, brown, etc.

  • Powder Coating

The large diameter aluminum tubes can be coated to any RAL color and metallic finish.

Need CNC Machining And Fabrication?

We provide services including hole punching, cut-to-length, drilling, laser cutting, CNC machining, bending to curved tube, welding, laser etching of logo and series number, assembly.

cnc machining-fonnovaluminium
aluminum bending-fonnovaluminium
aluminum profile assembly-fonnovaluminium

Professional Manufacturer of Large Diameter Aluminum Tubes

The alloy 6063 and 6061 are the most suitable aluminum alloys for producing large diameter aluminum tubes. We have rich experience in producing qualified large diameter aluminum tubes.

Our expertise is in producing extruded aluminum and machined aluminum. Such as aluminum profiles, custom aluminum extrusions, aluminum tubes, aluminum seamless tubes, aluminum rods, aluminum trims, aluminum beams and channels, aluminum heatsinks, etc. Our aluminum products are widely used in architecture, building and construction, vessel and ship, vehicles, and general industries.

Here are most of the questions related to large diameter aluminum tubes (large aluminum tube). We hope you will find the answer to your question. If not, please leave us a message.

What is a large-diameter aluminum tube?2023-12-05T03:03:46+00:00

You will find aluminum tubes in many industrial applications, from structural piping and pipeline to the latest aircraft. Many applications use different sizes of aluminum tubes – both small and large-diameter aluminum tubes.

Typically, the diameter of the large aluminum tube can be anywhere from 100-250mm onwards. Some of the tubes are as large as 650 mm in diameter. Based on your project requirements, you can order any custom size within the range from FONNOV ALUMINIUM. The best manufacturers will give the customer the freedom to request custom large-diameter aluminum tubes.

How are large aluminum tubes manufactured?2023-12-05T03:04:00+00:00

Here is the standard process for manufacturing large aluminum tubes:

  • Raw material in the form of aluminum billets arrives at our plant
  • The billets are cut according to the desired length
  • The aluminum billets are preheated to the specified temperature for the extrusion die
  • At least 100,000 PSI is applied to push the billet through the extrusion die
  • The extruded large aluminum tube is cooled, stretched, and cut to a specified length
  • Heat hardening follows to enhance corrosion resistance, strength, and durability
What are the main features of large diameter aluminum tubes?2023-09-23T03:18:31+00:00

The large-diameter aluminum tubes present similar features and advantages.

The alloys 6063 6061 6082 7075 2024 are often used to produce large aluminum tubes.

Despite the large diameter, these large aluminum tubes are easy to transport and pose fewer weight challenges when they build a structure. That explains why these tubes are popular for vehicles, buildings, and ship industries.

Large diameter aluminum tubes are also generally built for longevity and resistance to elements. If you pick the right manufacturer, you will get a tube that can serve you with consistent quality for a long time.

With the right provider, you are sure that the large aluminum tubes have been built according to national standards. That’s the mark of the best products.

What are the applications for large diameter aluminum tubes?2023-12-05T03:04:27+00:00

You can accomplish a lot with large diameter aluminum tubes. Whether you are in the oil & gas or transport sector, the applications of these products cut across different industries.



Energy

This is a popular industry for large aluminum tubes. The transmission systems in this industry require materials that have adequate electrical conductivity. Large tubes made from aluminum alloy are effective for such projects. In the renewable energy area, the tubes are prominent in the construction of wind turbines, whereby the strength and low weight play a critical role.



Transportation

Low weight and high strength is an irreplaceable combination in transportation designs. The versatility of the material allows for usage in vehicle manufacture.

How do you choose the best large diameter aluminum tubes?2023-09-23T03:26:45+00:00

Choosing the right large diameter aluminum tubes is a matter of considering the kind of project at hand more or less. Your project requirements will inform the criteria that you follow.

The purpose of the tubes will therefore be at the top of the criteria. Depending on the application or purpose of the tubes, there will be varying requirements for visual appeal, strength, profile, and corrosion resistance among other characteristics.

One thing that cuts across all large aluminum tubes is susceptibility to bending forces. An alloy that forms very easily may therefore not be the best for these types of tubes.

The alloy of the tubes does impact performance in different situations because it affects the properties of the product. Based on these properties, the product may be suitable or unsuitable for a particular application.

When it comes to the size and shape of the large aluminum tubes, it is important to note the possibility of these elements affecting the relevance or suitability of a product for an application. For instance, the shape of the tube can affect the suitability for carrying certain weights or loads.

Remember also to consider the project environment. For instance, if the tubes will be in a corrosive environment most of the time, insist on tubes that have high corrosion resistance.

There is also the matter of the temper. For projects where bending is a priority, we would recommend T4 temper. If the project focuses on hardness, then T6 temper is a perfect choice.

What aluminum alloys are suitable for large aluminum tubes?2023-09-23T03:35:53+00:00

Based on the strength, durability, weight, and other requirements for the large aluminum tubes in their popular applications, certain alloys of aluminum are preferable in the projects. The most common aluminum alloys for large tubes are 6063, 6060, 6061, and 6082. Others are 2024, 7075, and 5052.

Each of these aluminum alloys has unique characteristics that emanate from treatments with magnesium, copper, zinc, manganese, and other metals. 6061 aluminum, for instance, contains magnesium and silicon. These alloying elements make the metal highly corrosion-resistant and easy to weld. That’s part of the reason why this alloy is popular in industrial and structural projects. It is no wonder many large-diameter aluminum tubes are of this grade. This aluminum alloy does an excellent job with truck racks & frames and machine parts.

Then there is 5052 aluminum, which is an alloy containing magnesium. As you would expect, this material is extremely corrosion-resistant. It is so good that it is usable even in brine situations, although it is not the easiest to weld. Projects requiring large aluminum tubes in the chemical and marine environments are fond of this alloy of aluminum.

7075 aluminum is equally relevant in projects where large aluminum tubes are prominent. With its high zinc content, this aluminum alloy presents high strength. It is particularly common in the automotive and aerospace industries, where low weight and superior strength are required.

In some projects, the strength-to-weight ratio is the priority. Aerospace, aircraft, and transportation structural projects are in this category. Provided the environment is not rugged, 2024 aluminum comes in handy. The only possible challenge with the alloy is its relatively poor performance on corrosion resistance. Galvanizing the alloy with the right alloy can ward off rust from 2024 aluminum though.

How do large aluminum tubes compare to steel tubes?2023-09-23T03:38:01+00:00

Both aluminum tubes and steel tubes have their pros and cons when used in automotive, construction, aerospace, and other industries. However, each of the options offers specific characteristics that may be suitable for a project.

Steel is heavier and stronger than aluminum, so it is more capable of withstanding cracking and fracture. However, aluminum tubes perform better than mild steel in these aspects.

Aluminum tubes are more malleable than steel tubes, meaning that they are easier to extrude and form into custom profiles. When the temperatures fall, aluminum tubes cope better than steel tubes because they tend to be stronger.

Aluminum tubes are undoubtedly better than steel tubes in thermal conductivity and corrosion resistance. While aluminum is naturally protected by an oxide film, steel is prone to corrosion. Aluminum tubes have three times the thermal conductivity of steel tubes.

The same case applies to machinability, where the ease of working with and recycling large aluminum tubes. However, steel tubes are easier to weld.

Why buy large aluminum tubes from FONNOV ALUMINIUM?2023-09-23T03:50:20+00:00

With our two decades of experience serving different aluminum extrusion clients, we are convinced we are in a good position to offer some tips concerning large diameter aluminum tubes.

Choosing large diameter aluminum tubes from FONNOV ALUMINUM means being in a position to enjoy the benefits of products that are durable, high quality, and up to standard. We pride ourselves in being able to deliver the right products to our clients quickly once they have made the order.

We are experienced in producing all kinds of large aluminum tubes, even when the shapes are customized. FONNOV Aluminum is your one-stop shop for all alloys of large aluminum tubes.  Not many manufacturers can produce the profiles and specifications like the ones we do.

Work with the experts in large aluminum tubes! If you are looking for the ideal aluminum alloy for your project, we would be pleased to help. Contact Us today for suggestions.

What We need For Your Order or Quotation?

DWG (or PDF) File

The cross-section drawing includes dimension details, aluminum alloy and temper, length, dimension tolerance, critical dimensions, and inspection standard.

STEP File If Machining or Fabrication

If need CNC machining, bending, or assembly for your extrusion order, a STEP file will be necessary for our manufacturing. If need laser marking/etching of logo or series numbers, an AI (or CDR) file will be needed.

Finish & Color

Finish and color information is necessary for most architectural aluminum extrusion products. A super durable resistance request is also needed to provide for exterior use.

Quantity

Quantity is necessary information that you should provide us together with your drawing for quotation. Different order quantities will make price changes.
